Radio Quiet Zones

If you thought light pollution is bad (and it is!), radio pollution for radio astronomers is much worse.  Even years ago, terrestrial pollution of the radio spectrum tended to swamp faint celestial sources at many frequencies, and in 1958 the FCC established a 13,000 square mile rectangular region of West Virginia, Virginia, and Maryland as the National Radio Quiet Zone.  Two facilities within this protected region—whose natural topography helps to screen out many terrestrial radio emissions—are the Sugar Grove Station and the Green Bank Observatory near Green Bank, West Virginia.  The world’s largest fully-steerable radio telescope dish was built at Green Bank in 1956.  Though the original 300-ft. dish collapsed in 1988 due to a structural failure, it was rebuilt in 2000 as the Robert C. Byrd Green Bank Telescope, a leading facility for radio astronomy.

National Radio Quiet Zone

Counties wholly within the NRQZ, where many radio-emitting sources are regulated or banned outright, are Alleghany, Augusta, Bath, Highland, Nelson, and Rockbridge in Virginia, and Hardy, Pendleton, Pocahontas, Randolph, and Upshur in West Virginia.

The NRQZ isn’t the only radio quiet zone.  Here are some others:

  • Arecibo Observatory, Puerto Rico
  • Astronomy Geographic Advantage Act (AGAA), South Africa
  • Atacama Large Millimeter Array (ALMA), Chile
  • Australian Radio Quiet Zone WA (ARQZWA), Murchison Radio-astronomy Observatory (MRO)
  • Dominion Radio Astrophysical Observatory (DRAO), Canada
  • Five hundred meter Aperture Spherical Telescope (FAST), China
  • Institute for Radio Astronomy in the Millimeter Range (IRAM), Spain
  • Itapetinga Radio Observatory (IRO), Brazil
  • Large Millimeter Telescope (LMT), Mexico
  • Pushchino Radio Astronomy Observatory, Russia

The best place in the world to do radio astronomy is not on our world at all but instead on the far side of the Moon.  Radio telescopes deployed on the lunar farside could “listen” to the universe with absolutely no interference from Earth.  The solid body of the Moon (and its lack of an atmosphere) would completely block all radio signals and noise emanating from the Earth and Earth orbit.  And some radio telescopes could be quickly and easily deployed (think long-wire antennas rather than radio dishes).  Of course, the Moon itself will need to be designated as a radio quiet zone so that any lunar colonies, rovers, or satellites operate at frequencies and times that will not interfere with scientific work.  Maybe infrared or optical lasers would be a better way to communicate?

How would data from a lunar farside radio observatory be transmitted back to Earth?  One way would be to have a dedicated lunar satellite that receives data from the radio observatory while it is traveling over the lunar farside.  It would then re-transmit that data to Earth while it is traveling over the Earth-facing nearside.

Another (probably more expensive) approach would be to have a series of radio relay towers spaced at intervals from the radio observatory around to the lunar nearside where a transmitter could send the data back to Earth.

A third choice would be to locate the radio observatory in a libration zone along the border between the lunar nearside and farside.  At a libration zone radio observatory, data would be collected and stored until each time libration allows a direct line-of-sight to Earth.

The crater Daedalus, near the center of the lunar farside, has been suggested as the best location for a radio astronomy facility on the Moon (Pagana et al. 2006).

There is also a region above the farside lunar surface where radio emissions from Earth and Earth-orbiting satellites, would be blocked by the Moon, called the “Quiet Cone”, as illustrated in the diagram below.

The Earth-Moon L2 Lagrange point (EML2) is probably going to be within the lunar quiet cone.  Because L2 is an unstable Lagrange point, a radio telescope in the quiet cone would need to be in a halo orbit about EML2, and a tight one at that to avoid “seeing” any radio emissions from the highest Earth-orbiting satellites.

https://2.bp.blogspot.com/-ZQVqI6ob6jA/VVJbJS_DYDI/AAAAAAAABCM/jLNBE_lRVxU/s640/EarthMoon5LPoints.jpg

References
Antonietti, N.; Pagana, G.; Pluchino, S.; Maccone, C.
A proposed space mission around the Moon to measure the Moon Radio-Quiet Zone, 36th COSPAR Scientific Assembly. Held 16 – 23 July 2006, in Beijing, China.

Name That Comet

As of this writing, there are 3,635 comets named SOHO, over 300 comets named LINEAR, some 179 comets named PANSTARRS, 82 comets named McNaught, 62 comets named NEAT, and so on.

Except for the comets discovered by Scottish-Australian astronomer Robert H. McNaught (1956-), all of the above comets were discovered by various automated surveys.

SOHO = Solar and Heliospheric Observatory (spacecraft)

LINEAR = Lincoln Near-Earth Asteroid Research

Pan-STARRS = Panoramic Survey Telescope and Rapid Response System

NEAT = Near-Earth Asteroid Tracking

How do we distinguish between comets having the same name?  Each has a separate comet designation.  The first Comet LINEAR has a designation of P/1997 A2, and the most recent Comet LINEAR has a designation of C/2017 B3.

A comet designation starts with one of the following prefixes:

P/ – a periodic comet (orbital period < 200 years or confirmed observations at more than one perihelion passage)

C/ – non-periodic comet (orbital period ≥ 200 years and confirmed observations at only one perihelion passage)

X/ – comet for which no reliable orbit could be calculated (generally, historical comets)

D/ – a periodic comet that has disappeared, broken up, or been lost

A/ – an object that was mistakenly identified as a comet, but is actually a minor planet (asteroid, trans-Neptunian object, etc.)

I/ – an interstellar object that did not originate in our solar system

This is then followed by the year of discovery, a letter indicating the half-month of discovery, followed by the numeric order of discovery during the half-month.

So, we can see that the first Comet LINEAR, P/1997 A2, is a periodic comet discovered in 1997, between January 1 and January 15 of that year, and it was the second comet to be discovered during that period of time.  After the second perihelion passage, P/1997 A2 (LINEAR) was subsequently given the periodic comet number prefix of 230, so the full designation for this comet is now 230P/1997 A2 (LINEAR).

Likewise, the most recent Comet LINEAR (at the time of this writing), C/2017 B3, is a non-periodic comet discovered in 2017 between January 16 and January 31, the third comet discovered during that period of time.

Interestingly, if different periodic comets have the same name, they are sequentially numbered.  Perhaps the most famous example is Comet Shoemaker-Levy 9 that broke up and crashed into Jupiter during July 1994.  There are a total of nine periodic comets named Shoemaker-Levy.  They are:

192P/1990 V1   Shoemaker-Levy 1
137P/1990 UL3  Shoemaker-Levy 2
129P/1991 C1   Shoemaker-Levy 3
118P/1991 C2   Shoemaker-Levy 4
145P/1991 T1   Shoemaker-Levy 5
181P/1991 V1   Shoemaker-Levy 6
138P/1991 V2   Shoemaker-Levy 7
135P/1992 G2   Shoemaker-Levy 8
D/1993 F2      Shoemaker-Levy 9

However, four additional non-periodic comets were discovered by the Carolyn & Gene Shoemaker and David Levy team.  They have not received a numeric suffix and are all called “Comet Shoemaker-Levy”:

C/1991 B1      Shoemaker-Levy
C/1991 T2      Shoemaker-Levy
C/1993 K1      Shoemaker-Levy
C/1994 E2      Shoemaker-Levy

This strikes me as a bit strange.  Why afford a numeric suffix to a comet name only when it is a periodic comet?  Why not give all comets named “Shoemaker-Levy” a numeric suffix.  Normally, we would number them all in order of discovery, but since the nine periodic comets have already received a number, we would have to number the four non-periodic comets as C/1991 B1 (Shoemaker-Levy 10), C/1991 T2 (Shoemaker-Levy 11), C/1993 K1 (Shoemaker-Levy 12), and C/1994 E2 (Shoemaker-Levy 13).

I would like to see all comets, both periodic and non-periodic, receive a numeric suffix to their names whenever there is more than one.  So, instead of Comet LINEAR we would have Comet LINEAR 1, Comet LINEAR 2, Comet LINEAR 3, and so on.

By the way, the days of amateur astronomers discovering a new comet are probably over.  Though this is a little sad, it does tell us that the entire sky is being monitored much more closely than in the past, by a number of automated surveys.  And that is a good thing, because we will be much less likely to miss anything “new” in the sky.

None of the comets this year (so far) have been discovered by amateurs.  Here is the current tally of comet discoveries (or recoveries) this year:

Pan-STARRS (Panoramic Survey Telescope and Rapid Response System)
C/2018 A1 (PANSTARRS)
364P/2018 A2 (PANSTARRS)
C/2018 A4 (PANSTARRS)
P/2018 A5 (PANSTARRS)
C/2018 F4 (PANSTARRS)
P/2018 H2 (PANSTARRS)
P/2018 L1 (PANSTARRS)
P/2018 L4 (PANSTARRS)
P/2018 P3 (PANSTARRS)
P/2018 P4 (PANSTARRS)
C/2018 P5 (PANSTARRS)
372P/2018 P6 (McNaught) [recovery of P/2008 O2]

ATLAS (Asteroid Terrestrial-impact Last Alert System)
C/2018 A3 (ATLAS)
C/2018 E1 (ATLAS)
C/2018 K1 (Weiland) [H. Weiland, ATLAS]
C/2018 L2 (ATLAS)
C/2018 O1 (ATLAS)

MLS (Mt. Lemmon Survey)
C/2018 A6 (Gibbs) [A.R. Gibbs, MLS]
C/2018 B1 (Lemmon)
P/2018 C1 (Lemmon-Read) [M.T. Read, Spacewatch, Kitt Peak]
C/2018 C2 (Lemmon)
C/2018 EF9 (Lemmon)  [originally classified as an asteroid]
C/2018 F1 (Grauer) [A.D. Grauer, MLS]
C/2018 F3 (Johnson) [J.A. Johnson, MLS]
C/2018 KJ3 (Lemmon) [originally classified as an asteroid]
P/2018 L5 (Leonard) [G. Leonard, MLS]
C/2018 R3 (Lemmon)
C/2018 R5 (Lemmon)

SONEAR (Southern Observatory for Near Earth Asteroid Research)
C/2018 E2 (Barros) [Joao Barros, SONEAR]

NEOWISE (Near-Earth Object Wide-field Infrared Survey Explorer)
C/2018 EN4 (NEOWISE)  [originally classified as a Centaur asteroid]
C/2018 N1 (NEOWISE)

Spacewatch
366P/2018 F2 (Spacewatch)

CSS (Catalina Sky Survey)
367P/2018 H1 (Catalina)
C/2018 M1 (Catalina)
C/2018 R4 (Fuls) [D.C. Fuls, CSS]

NEAT (Near-Earth Asteroid Tracking)
368P/2018 L3 (NEAT)
370P/2018 P2 (NEAT)

ASAS-SN (All Sky Automated Survey for SuperNovae)
C/2018 N2 (ASASSN)

OGS (ESA Optical Ground Station)
369P/2018 P1 (Hill) [recovery of P/2010 A1]
371P/2018 R1 (LINEAR-Skiff) [recovery of P/2001 R6]

373P/2018 R2 (Rinner)  [Jean-Francois Soulier, Maisoncelles, and Krisztian Sarneczky, University of Szeged, Piszkesteto Station (Konkoly), independently recovered P/2011 W2]

374P/2018 S1 (Larson) [Krisztian Sarneczky and Robert Szakats, University of Szeged, Piszkesteto Station (Konkoly), recovered P/2007 V1]

375P/2018 T1 (Hill) [Krisztian Sarneczky, University of Szeged, Piszkesteto Station (Konkoly), recovered P/2006 D1]

Cosmology: The History and Nature of Our Universe

Mark Whittle, Professor of Astronomy at the University of Virginia, has put together the most comprehensive and comprehensible treatment on the subject of cosmology that I have ever encountered.  Cosmology: The History and Nature of Our Universe, a series of 36 thirty-minute video lectures for The Great Courses (Course No. 1830), is a truly remarkable achievement.

Even though this course was released ten years ago in 2008, all of the material is still completely relevant.  This is the course on cosmology that I’ve always wanted but never had.  Enjoy!

Cosmology has come a long ways since I was a physics and astronomy student at Iowa State University from 1975-1980, and again in 1981, 1984, and 2000-2005.  I’m glad to see a course specifically about cosmology is now offered at a number of universities.  When I was an undergraduate student at ISU, it was unheard of.  The University of Wisconsin at Madison Department of Astronomy currently offers both an undergraduate and a graduate course in cosmology: Astronomy 335 – Cosmology, and Astronomy 735 – Observational Cosmology.  And the Department of Physics & Astronomy at Iowa State University now offers an undergraduate/graduate dual-listed cosmology course: Astro 405/505 – Astrophysical Cosmology.

When I retire in a few years, I would love to be a “fly on the wall” at the UW-Madison astronomy department.  Wonder if they could use an expert SAS programmer to help analyze the massive quantities of data they surely must have?  (Though the last time I interviewed for an astronomy job, at the McDonald Observatory in Texas, the interviewers had never heard of SAS but asked if I knew Python, which of course is what nearly everyone is looking for and using these days.  Tomorrow, it will be something else…).  In retirement, at the very least I would love to immerse myself in a few astronomy courses at UW-Madison.  Something to look forward to!

Blue Light Blues

One by one, all of our warm white lights are being replaced by cold, harsh, bluish-white LEDs.  And it is happening fast.

Everywhere.  In our streetlights, our workplaces, even our homes.  How do you like looking into those blue-white vehicle headlights as compared with the yellow-white ones we have been using since the automobile was invented?

LED lighting is the way of the future, don’t get me wrong, but we should be specifying and installing LED lights with a correlated color temperature (CCT) of 2700K or 3000K—with few exceptions—not the 4000K or higher that is the current standard.

Why is 4000K the current standard?  Because blue-white LEDs have a slightly greater luminous efficacy than yellow-white LEDs.  Luminous efficacy is the amount of light you get out for the power you put in, often measured in lumens per watt.  But should luminous efficiency be the only consideration?  What about aesthetics?  In addition to luminous efficacy, there are other, more significant ways to reduce power consumption and greenhouse gas emissions:

  • Use the minimum amount of light needed for the application; no need to overlight
  • Use efficient light fixtures that direct light only to where it is needed; near-horizontal light creates annoying and visibility-impairing glare and light trespass, and direct uplight into the night sky is a complete waste
  • Produce the light only when it is needed through simple switches, time controls, and occupancy sensors; or, use lower light levels during times of little or no activity

Even the super-inefficient incandescent light bulb (with a CCT of 2400K, by the way), operating three hours each night uses less energy than the light source with the highest luminous efficacy operating dusk to dawn.  Think about it.

In my town, as in most now, the soothing orange 1900K high pressure sodium (HPS) streetlights are being replaced with 4000K LEDs.  That’s a big change.  It will completely transform our outdoor nighttime environment.  Warm-white compact fluorescents are 2700K, and even tungsten halogen bulbs are 3000K.  Do we really want or need 4000K+ LEDs?

We are currently witnessing a complete transformation of our illuminated built environment.  Not enough questions are being asked nor direction being given by citizens, employees, and municipalities.  The lighting industry generally wants to sell as many lights as possible at the highest profit margin.  We as lighting consumers need to make sure we have the right kind of light, the right amount of light, and lighting only when and where it is needed.
